MINIMUM IMPACT ON SUPPLIES

EASY SOURCE:

• Input current distortion <4% for the 9312C/9332C with filter with sinusoidal absorption to remove the risk of resonance with other input supply users or phase shift capacitor sets. The absorbed current distortion is independent of input supply parameters such as impedance. This enables 9312C/ 9332C to deliver maximum performance levels regardless of the installation environment.

MAXIMUM BATTERY CARE:

• Battery deep discharge protection;
• Temperature compensating charger;
• Built-in automatic and manual battery test feature.

SIMPLE TO INSTALL:

• Capability to install the UPS into any distribution system (Neutral not required on rectifier input);
• Capability to separate the rectifier/bypass power network and to power these from two separate sources, without Galvanic isolation (Necessary on UPS without an output transformer).

HIGH RELIABILITY:

• Extremely high short-circuit current to ensure compatibility with the most difficult transformer applications (lighting, drives and industrial processes) and an isolation transformer on the inverter output;
• Full microprocessor control with no-break static and manual by-passes

MAXIMUM RELIABILITY AND AVAILABILITY:

Connect up to 6 units in parallel or N+1 redundancy, even of different power ratings. The UPS continue to work in parallel even if one of the interconnecting communication cables is disconnected (CLOSED LOOP).

LOW CONSUMPTION LEVELS:

APS9312C/APS9332C can achieve efficiencies >98% thanks to selectable Economy Mode which can be used in stable electrical environments to provide power supply continuity when the mains fail.
