Features:

• Superior energy saving and environment-friendly:

Efficiency > 96% at 50%-75% rated load, and > 95% at 25% rated load; Input PF > 0.99, input THDi<3%

• Superior capability of powering load:

Output PF is 0.9, no need of power duration with load of leading or lagging PF

• Easy-to-install:

Top or bottom cabling, no need of input cabling cabinet

• Easy-to-maintain:

Full front access, UPS, failed part can be replaced shortly

• Easy-to-modify:

The number of battery cells can be configured flexibly, so the original batteries can be used when modifying the legacy system; moreover, the battery cell can be replaced in time when it fails without interrupting the normal operation of UPS.

•  6-inch extra large LCD that can display 12 l a n g u a g e (English, Chinese , Russian, French, Spanish and so on)

Static switch module:

• System standard configuration module
• Adopt SCR and AC contactor in parallel
• High reliability, strong overloads ability: 1000% for 1min
• Transfer time less than 4ms
• Have strong self-test, inter-lock and full-protection function

Power module:

• Freedom choice of capacity configuration according demand, easy to expand
• Online double-conversion design to ensure the output quality
• Each module has independent digital intelligent control
• Each module can work independently
• Each module has a separate charging system
• All modules can be hot-swappable, easy for online maintenance
