DC output ：
- Rated voltage 48V
- Voltage range: 42-60V
- Rated Current: 30A/45A/60A/90A
- Load Distribution: 4 outlet load
- Battery Distribution: 1 outlet battery
- Battery LVD: 100A×1
- Mode of connection: Connect terminal to front panel
- Rectifier Module: SR4810, SR4815,SR4820,SR4830
- Monitoring Module: STM-1
Mechanical characteristic :
- Dimensions(W H D): 482.6 88 280(mm)
- Weight(Kg); 10kg (include rectifier module)
| Rated input voltage | 220V |
|---|---|
| AC input Voltage range | 85-300V |
| AC input Frequency range | 45-66HZ |
| Power factor | ≥0.99 |
| Efficiency | >92% |
