DC Output:
- Voltage range 43V-59V
- Current Ratings :30A 20A 15A 10A
- Source effect:≤±0.1%
- Load effect :≤±0.5%
- Stabilized voltage precision :≤±0.6%
- Soft-startup Time :6S
Mechanical characteristic
- Dimensions (W×H D)：126 44(1U)X213.4mm
- Weight: 1.5KG
| Rated voltage | 230V |
|---|---|
| Voltage range | 85V-350VAC/ 90V-380VDC |
| Frequency range | 45-65Hz 、 |
| Max. Current | 10A(30A)、7.5A(20A)、5.6A(15A)、3.7A(10A) |
| Power factor | 0.99 |
| Efficiency : | 92% |
